Moteur de véhicule EURO II
| Model | 4DX12-96 | 4DX22-110 | 4DX22-120 |
| Type | 4-cylinder in-line, direct injection, water cooling, turbocharged | ||
| Bore×Stroke (mm) | 100×100 | 102×118 | |
| Valves/cylinder | 2 | ||
| Displacement (L) | 3.142 | 3.857 | |
| Rated power | 70.6 | 81 | 88 |
| Rated speed (r/min) | 3200 | ||
| Net power/speed (kW/r/min) | 68 | 79 | 86 |
| Maximum torque (Nm) | 245 | 324 | 343 |
| Maximum torque speed (r/min) | 2000 ~ 2200 | 1800-2000 | |
| Fuel consumption (g/kW·h) | 225 | ||
| Smoke (m-1) | ≤ 3.0 | ||
| Noise dB(A) | ≤ 95.5 | ||
| Emission Compliant (TAS) | EURO Ⅱ | ||
| Net Mass (kg) | 380 | ||
| Length×Width×Height (mm) | 810×700×850 | ||
| Model | 4DX13-96 | 4DX13-104 | 4DX23-110 | 4DX23-120 | 4DX23-130 |
| Type | 4-cylinder in-line, direct injection, water cooling, turbocharged inter-cooled | ||||
| Bore×Stroke (mm) | 100×100 | 102×118 | |||
| Valves/cylinder | 2 | ||||
| Displacement (L) | 3.142 | 3.857 | |||
| Rated power | 70.6 | 76.5 | 81 | 88 | 95.5 |
| Rated speed (r/min) | 3000 | 2800 | |||
| Net power/speed (kW/r/min) | 68 | 74 | 78 | 85 | 92 |
| Maximum torque (Nm) | 260 | 285 | 324 | 343 | 380 |
| Maximum torque speed (r/min) | 1900~2100 | 1800~ 2100 | |||
| Fuel consumption (g/kW·h) | 225 | ||||
| Smoke (m-1) | ≤ 3.0 | ||||
| Noise dB(A) | ≤ 95.5 | ||||
| Emission Compliant (TAS) | EURO Ⅱ | ||||
| Net Mass (kg) | 380 | ||||
| Length×Width×Height (mm) | 810×700×850 | ||||
